Quadrel Labeler
Applicable to the circumferential labeling of PET, PP,PE round bottle opp film, pearlfilm, paper plastie composite film and other industries in washing, beverage,mineral water,food and other industries, To ensure the aesthetics of product packaging,but also greatly reduce the cost of packaging materials.
This quadrel Labeler is a new type of rotary and continuous labeling machine. The equipment can automatically adjust the in and out transmission of the container; the container conveyed by the conveyor belt is separated by a certain distance by the bottle-separating screw according to the spacing of the star wheel, and then the imported star wheel transfers the container to the container turntable. After the container is fixed by the mold base of the container, the container starts to rotate at a certain speed; and the positioning and labeling are carried out according to the trajectory of the mechanism.
Features
1. This quadrel labeler adopts Schneider servo motor and Siemens PLC control, it is not only easy to operate but also stable and reliable.
2.The bottle pressing head is electrically lifted and lowered, and the height of the replacement product can be operated on the man-machine interface, which is easy to adjust.
3. The production speed is fast, and it can be produced in line with the filling line, which greatly improves the production speed and saves costs.
4. The machine interface can display the actual status of the machine, output, hot melt adhesive temperature, glue coating temperature and other information at a glance, which is convenient for users to troubleshoot, easy to operate, easy to learn, and can be manually started or jogged when debugging or changing labels, which is convenient to operate.（As shown below）
①Press the bottle head (press the bottle)
② Bottle holder (holding the bottle)
③ Knife drum (cut off the label)
④ Label drum (suck the cut label and move to the glue drum, so that the head and tail of the label are glued with glue, and then the label is glued to the bottle)
⑤ Glue roller (pump the melted glue onto the metal rod and apply glue to the label)
⑥ Glue box (storage glue)
⑦ Deviation correction device (automatic correction of deviation during label movement)
⑧ Label plate (put label roll)
FAQ
Q1. What's your transportation way?
A1. LCL and FCL by sea, by express and by air.
Q2. How about your packing?
A2. Professional export package,wooden case
Q3. What are your payment terms?
A3. T/T in advance
Q4. What is the lead time ?
A4. Generally if we have stock, we will deliver the machine in one week. If it need custom made, the lead time will be around 20-50 days which depends on the real situation.
Q5. How does your factory control the quality?
A5. Quality is very important, we take much attention to control our quality from raw materials to the end. We will test every machine before it leaves our factory to make sure it's working good. Our factory has passed ISO. We also have audit periodically to make sure our products qualified.
